Deutz BFM3G1 diesel generator sets features:
High quality power generators with DEUTZ engines (Made in Germany) . The attractive super silent enclosures are weatherproof and well below the permitted noise emission standards significantly.
Engine Brands: Powered by Cummins,Powered by Perkins,Powered by Lovol,Powered by Deutz,Powered by Doosan, Powered by Mitsubishi, Powered by Yuchai or other
reliable Chinese engines such as Fawde and Laidong.
Rated output: 2 to 2,000kW/2 to 2,500kVA
Rated voltage: L-N 110 to 277V, L-L 220 to 480V
Rated frequency: 50/60Hz
Cooling method: closed water-cooled or air-cooled
Starting method: electric start or recoil start
Rated speed: 1,500/1,800/3,000/3,600rpm
Noise level: 56 to 75dB, 7 meters away
| Manufacturer | Changsha Mingbang Intelligent Technology Co.Ltd | | Model | MB-30 | | Prime Powder | 30KW/37.5KVA | | Power Factor | COSΦ=0.8(lagging) | | Max. Output current | 54A | | Genset Weight | 600kg(Net) | | Length x Width x Height (Engine) (mm) | 1600*700*1150 | | Voltage | 400/230V | | Frequency | 50HZ | | Deutz Engine Specification | | Manufacturer | Dalian Deutz Engine Co., Ltd | | Model | BFM3G2 | | Rated speed | 1500rpm | | Prime Powder | 32KW/40KVA | | Fuel Consumption | <=210g/KW.H | | Lube oil capacity | 7.5L | | Bore (mm) x Stroke (mm) | 98*105mm | | Compression ratio | 18.5:1 | | Displacement (litre) | 3.2 | | Coolant capacity, L | 10.2L | | Configuration | 4 in line ,four-stroke, Turbocharged, Charge Air Cooled | | Cooling | Liquid Cooled | | Governor type | Electronic | | Starting voltage | 24 Volts DC | | Filtration system | Air Filter/Fuel Filter/Oil Filter | | Stamford Alternator Specification | | Manufacturer | Changsha Mingbang Intelligent Technology Co.Ltd | | Model | MBC22A | | Voltage Regulator | AVR | | Voltage adjust range | ±1% | | Rated Voltage/Frequency/Factor | 400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire | | Steady-state Frequency | 5% | | No-load Voltage Adjust Range | >=95%-105% | | Insulation Class | H | | IP Protection | 22 | | Excitation Type | Blushless | | |
About MingBang Intelligent Technology
Mingbang Intelligent Technology Co.,LTD was established in 2005,occupies an area of 5042 square meters,located in Yangzhou city,Jiangsu Province,which is the central part of manufacturing industry zone in Southeast China near Shanghai
Mingbang works closely with all large power manufactures such as Cummins, Perkins, Deutz,
Volvoand Chinese local brands SDEC,Yuchai,Jichai diesel generator sets,engines with
Stamford,Marathom,Leroy-Somer,and MBKL manufactured alternators ,and so on. Key diesel
generator stock ranges from 10KVA to 3000 KVA, classifying silent generator, open generator ,
container generator, mobile genset, and so on.
Whether you require support for an office, residential development ,industrial development or
shopping centre, hospital,railways,prison, hotal, airport ,bank data centre, Mingbang will
support you the most reliable and most cost-efficient generators and accessories.
Weclome to visit our factory!
Prime Power 50HZ 37 KVA 30KW Open Tyep Deutz Diesel Generator BFM3G2 Deutz Engine
Main Features
| Product Overview | |
| 1) Brand-new engine,w/start motor. | |
| 2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR. |
| 3) Auto control panel with LCD display. | |
| 4) Engine mounted battery-charging alternator,Genset with battery charge of main supply. |
| 5) Circuit Breaker,Exhaust Silencer. | |
| 6) Copper Radiator for 40℃ ambient temperature and double-deck cooling,with fan guard and front guard. |
| 7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable. |
| 8) Skid-mounted bottom 8 hours fuel tank. | |
| 9) Extemal recessed emergency stop button for extra safety. |
| 10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system. |
